Description
LCD OPTIONS
173W: LED Backlit, FHD, 1920 x 1080 (Max Res)
173W: LED Backlit, FHD, 1920 x 1080 (Max Res)
- Backlight: 400 NITS, LED
- Operational Temp: -0º C to 70º C
- Storage Temp: -20º C to 70º C
- Viewing Angles: 80-80-60-80
- Contrast Ratio: 600:1
- Response Time: 40ms
- Color: 16.7M (6 Bit + Hi-FRC)
- Color Gamut: 72%
173HB: High Bright, FHD, 1920 x 1080 (Max Res)
173HB: High Bright, FHD, 1920 x 1080 (Max Res)
- Backlight: 1000 NITS, LED
- Operational Temp: -0º C to 70º C
- Storage Temp: -20º C to 70º C
- Viewing Angles: 80-80-60-80
- Contrast Ratio: 600:1
- Response Time: 40ms
- Color: 16.7M (6 Bit + Hi-FRC)
- Color Gamut: 72%
Optional Enhancements and Upgrades
- Optical Bonding
- Conformal Coating of Electronics
- PCAP and Resistive Touch
- Much More!!
Ask your sales engineer for more information.
VIDEO CONTROLLERS
Note: The boards shown below have multiple inputs available but might be more then needed for your project. Certain assemblies might restrict our abilities to bring every port out of board. Please speak to one of our sales engineers to dial in a configuration that matches your needs.
V33x Industrial Grade
V33x Industrial Grade
- Max resolution: 1920 x 1200
- Input Options Available: VGA, HDMI, Display Port
V35x Embeded
V35x Embeded
- Max resolution: 1920 x 1200
- Input Options Available: VGA, (DVI-D or HDMI or 3G-SDI), and Display Port
Front Face Fixed Configurations
D8: Most Popular Front Face, with Double Thumb Screw / 5″ Flush Collapsible Handle
D8: Most Popular Front Face, with Double Thumb Screw / 5" Flush Collapsible Handle
Double Thumbscrew Front Face with 5″ Collapsible Handle
D1: Standard Front Face, with Double Thumb Screw / Pocket Pull Handle
D1: Standard Front Face, with Double Thumb Screw / Pocket Pull Handle
Our standard front face with two thumbscrews on either side, with a sleek and space saving pocket pull handle.
Da1: Integrated Audio Front Face, with Double Thumb Screw/ Pocket Pull Handle
Da1: Integrated Audio Front Face, with Double Thumb Screw/ Pocket Pull Handle
An audio enhanced front face with two thumbscrews and a space saving pocket pull handle.
D7: Standard Front Face, with Double Thumb Screw / 5″ Flush Collapsible Handle
D7: Standard Front Face, with Double Thumb Screw / 5" Flush Collapsible Handle
Our standard front face with two thumbscrews, and a 5″ solid collapsible handle that lays flush with the front face.
Da7: Integrated Audio, Double Thumb Screw / 5″ Flush Collapsible Handle
Da7: Integrated Audio, Double Thumb Screw / 5" Flush Collapsible Handle
An audio enhanced front face with two thumbscrews, and a 5″ solid collapsible handle that lays flush with the front face.
Mix and Match Front Face And Pull Handle Options
Pick a front face of your choice and a handle to suite your needs.
D: Standard Front Face, with Double Thumb Screw, U-Pick Handle
D: Standard Front Face, with Double Thumb Screw, U-Pick Handle
Our standard front face with two thumbscrews and the choice of handle to suite your needs.
Da: Integrated Audio Front Face, With Double Thumb Screw, U-Pick Handle
Da: Integrated Audio Front Face, With Double Thumb Screw, U-Pick Handle
An audio enhanced version of the standard front face with thumbscrews and the choice of handle to suite your needs.
2: 3″ Chrome Wire Pull
2: 3" Chrome Wire Pull
Compact 3″ chrome plated pull mounted on face of your choice.
3: 4″ Chrome Wire Pull
3: 4" Chrome Wire Pull
4″ chrome plated pull mounted on face of your choice.
4: 6″ Chrome Wire Pull
4: 6" Chrome Wire Pull
Robust 6″ chrome plated wire pull mounted on face of your choice.
5: 4″ Brushed Aluminum Pull
5: 4" Brushed Aluminum Pull
Smooth 4″ brushed aluminum pull mounted on face of your choice.
6: 7.5″ Stainless Steel Pull
6: 7.5" Stainless Steel Pull
Solid 7.5″ stainless steel pull mounted on face of your choice.
8: 5″ Collapsible Pull
8: 5" Collapsible Pull
Convenient and sturdy 5″ collapsible pull mounted on face of your choice in a black finish.
9: Heavy Duty Pull (Hydra 21.5" Only)
Panel Configuration Options
2 Panel Options
3 Panel Options
4 Panel Options
