DTS-PMxx

Request Data Sheet
Category: Panel Mount LCD Display
  • Description
  • Request Quote

Description

  • Features

    • Customizable Modular Design.
    • LED Backlit LCDs
    • Various Panel Sizes and Aspect Ratios
    • IP67-Rated Front Face and OSD Panel

LCD OPTIONS

15HB: High Bright XGA 1024 x 768 (Max Res):

15LHB_ud_arrow1


  • Backlight: 1000+ NITS, LED
  • Operational Temp: -20* to 70* C
  • Viewing Angles: 80-80-80-60
  • Contrast Ratio: 750:1
  • Response Time: 18ms

17L: LED Backlit, SXGA, 1280 x 1024 (Max Res)

17L_UD_arrows


  • Backlight: 350 NITS, LED
  • Operational Temp: -30* to 85* C
  • Viewing Angles: 85-85-80-80
  • Contrast Ratio: 1000:1
  • Response Time: 5ms

17HB: High Bright, SXGA, 1280 x 1024 (Max Res)

17HB_UD_arrows


  • Backlight: 1000+ NITS, LED
  • Operational Temp: -30* to 85* C
  • Viewing Angles: 85-85-80-80
  • Contrast Ratio: 1000:1
  • Response Time: 5ms

19L: LED Backlit, SXGA, 1280X1024 (Max Res)

19L_UD_arrow


  • Backlight: 350 NITS, LED
  • Operational Temp: 0* to 50* C
  • Viewing Angles: 85-85-80-80
  • Contrast Ratio: 1000:1
  • Response Time: 5ms

19HB: High Bright, SXGA, 1280X1024 (Max Res)

19HB_UD_arrows


  • Backlight: 1000+ NITS, LED
  • Operational Temp: 0* to 50* C
  • Viewing Angles: 89-89-89-89
  • Contrast Ratio: 2000:1
  • Response Time: 0

173HB: High Bright, FHD, 1920 x 1080 (Max Res)

173hb


  • Backlight: 1000+ NITS, LED
  • Operational Temp: 0* to 70* C
  • Viewing Angles: 80-80-60-80
  • Contrast Ratio: 600:1
  • Response Time: 40ms

*Additional LCD options available.


VIDEO CONTROLLERS

V23xM High End, Military, Conformal Coated, Long Road Map

v15x-aligned


  • Max resolution: 1920 x 1200
  • Input Options Available: VGA, DVI-D, HDMI, 2xCVS (Composite), YPbPr , (Component), IP50 or RS232 Controls, Optional 1 or 2 Channel 3G HD-SDI, Optional Audio, Dual Digital-Picture in Picture

V33x

V23x High End

a


  • Max Resolution: 1920 x 1200
  • Input Options Available: VGA, HDMI, and DP

*Additional controller options available.
