Description
- Rugged all aluminum construction
- Customizable modular design
- Mil spec friction rails
- Held closed by cam lock
- Held open by heavy duty torque hinge
- Intergrated slides with mounting brackets
19L: LED Backlit, SXGA, 1280X1024 (Max Res)
![19L: LED Backlit, SXGA, 1280X1024 (Max Res) 19L: LED Backlit, SXGA, 1280X1024 (Max Res)](https://www.dithd.com/wp-content/uploads/2014/06/19L_UD_arrow.png)
19L: LED Backlit, SXGA, 1280X1024 (Max Res)
- Backlight: 350 NITS, LED
- Operational Temp: 0* to 50* C
- Viewing Angles: 85-85-80-80
- Contrast Ratio: 1000:1
- Response Time: 5ms
Note: Alternate Panel with Higher Specs Available.
19HB: High Bright, SXGA, 1280X1024 (Max Res)
![19HB: High Bright, SXGA, 1280X1024 (Max Res) 19HB: High Bright, SXGA, 1280X1024 (Max Res)](https://www.dithd.com/wp-content/uploads/2014/06/19HB_UD_arrows.png)
19HB: High Bright, SXGA, 1280X1024 (Max Res)
- Backlight: 1000+ NITS, LED
- Operational Temp: 0* to 50* C
- Viewing Angles: 89-89-89-89
- Contrast Ratio: 2000:1
- Response Time: 0
173W: LED Backlit, FHD, 1920 x 1080 (Max Res)
![173W: LED Backlit, FHD, 1920 x 1080 (Max Res) 173W: LED Backlit, FHD, 1920 x 1080 (Max Res)](https://www.dithd.com/wp-content/uploads/2014/06/173w1-300x201.png)
173W: LED Backlit, FHD, 1920 x 1080 (Max Res)
- Backlight: 400 NITS, LED
- Operational Temp: 0* to 70* C
- Viewing Angles: 80-80-60-80
- Contrast Ratio: 600:1
- Response Time: 40ms
173HB: High Bright, FHD, 1920 x 1080 (Max Res)
![173HB: High Bright, FHD, 1920 x 1080 (Max Res) 173HB: High Bright, FHD, 1920 x 1080 (Max Res)](https://www.dithd.com/wp-content/uploads/2014/06/173hb2-300x201.png)
173HB: High Bright, FHD, 1920 x 1080 (Max Res)
- Backlight: 1000+ NITS, LED
- Operational Temp: 0* to 70* C
- Viewing Angles: 80-80-60-80
- Contrast Ratio: 600:1
- Response Time: 40ms
V17x Mid Range, Light Industrial
![V17x Mid Range, Light Industrial V17x Mid Range, Light Industrial](https://www.dithd.com/wp-content/uploads/2014/06/v17Aaxaligned-300x240.png)
V17x Mid Range, Light Industrial
- Max resolution: 1920 x 1200
- Input Options Available: VGA, Displayport, HDMI, Audio
V23X Controller
![V23X Controller V23X Controller](https://www.dithd.com/wp-content/uploads/2014/06/V25aligned-300x240.png)
V23X Controller
- Max Resolution: 1920 x 1200
- Input Options Available: VGA, HDMI, Display Port,
V25X Entry Level, Embedded, Light Industrial
![V25X Entry Level, Embedded, Light Industrial V25X Entry Level, Embedded, Light Industrial](https://www.dithd.com/wp-content/uploads/2014/06/V25aligned-300x240.png)
V25X Entry Level, Embedded, Light Industrial
- Max Resolution: 1920 x 1200
- Input Options Available: VGA, DVI or HDMI, Display Port, Audio
Front Face Fixed Configurations
![A1: Standard Front Face, with Cam Lock / Pocket Pull Handle A1: Standard Front Face, with Cam Lock / Pocket Pull Handle](https://www.dithd.com/wp-content/uploads/2014/06/A1-300x30.png)
A1: Standard Front Face, with Cam Lock / Pocket Pull Handle
A1: Standard Front Face, with Cam Lock / Pocket Pull Handle
Our standard front face with cam lock and a space saving pocket pull handle.
D1: Standard Front Face, with Double Thumb Screw / Pocket Pull Handle
Our standard front face with two thumbscrews on either side, with a sleek and space saving pocket pull handle.
![Da1: Integrated Audio Front Face, with Double Thumb Screw/ Pocket Pull Handle Da1: Integrated Audio Front Face, with Double Thumb Screw/ Pocket Pull Handle](https://www.dithd.com/wp-content/uploads/2014/06/Da1-300x120.png)
Da1: Integrated Audio Front Face, with Double Thumb Screw/ Pocket Pull Handle
Da1: Integrated Audio Front Face, with Double Thumb Screw/ Pocket Pull Handle
An audio enhanced front face with two thumbscrews and a space saving pocket pull handle.
![D7: Standard Front Face, with Double Thumb Screw / 5" Flush Collapsible Handle D7: Standard Front Face, with Double Thumb Screw / 5" Flush Collapsible Handle](https://www.dithd.com/wp-content/uploads/2014/06/D7iso-300x120.png)
D7: Standard Front Face, with Double Thumb Screw / 5″ Flush Collapsible Handle
D7: Standard Front Face, with Double Thumb Screw / 5" Flush Collapsible Handle
Our standard front face with two thumbscrews, and a 5″ solid collapsible handle that lays flush with the front face.
![Da7: Integrated Audio, Double Thumb Screw / 5" Flush Collapsible Handle Da7: Integrated Audio, Double Thumb Screw / 5" Flush Collapsible Handle](https://www.dithd.com/wp-content/uploads/2014/06/Da71-300x120.png)
Da7: Integrated Audio, Double Thumb Screw / 5″ Flush Collapsible Handle
Da7: Integrated Audio, Double Thumb Screw / 5" Flush Collapsible Handle
An audio enhanced front face with two thumbscrews, and a 5″ solid collapsible handle that lays flush with the front face.
Mix and Match Front Face And Pull Handle Options
Pick a front face of your choice and a handle to suite your needs.
![B: Standard Front Face, with Cam Lock, U-Pick Handle option B: Standard Front Face, with Cam Lock, U-Pick Handle option](https://www.dithd.com/wp-content/uploads/2014/06/FaceB-300x28.png)
B: Standard Front Face, with Cam Lock, U-Pick Handle option
B: Standard Front Face, with Cam Lock, U-Pick Handle option
Our standard front face with a high security cam lock and a choice of handle to suite your needs.
Ba: Integrated Audio Front Face, with Cam Lock, U-Pick Handle option
An Audio enhanced front face with a high security cam lock and a choice of handle to suite your needs.
C: Standard Front Face, with Double Thumb Latch, U-Pick Handle option
D: Standard Front Face, with Double Thumb Screw, U-Pick Handle
![D: Standard Front Face, with Double Thumb Screw, U-Pick Handle D: Standard Front Face, with Double Thumb Screw, U-Pick Handle](https://www.dithd.com/wp-content/uploads/2014/06/D-300x120.png)
D: Standard Front Face, with Double Thumb Screw, U-Pick Handle
Our standard front face with two thumbscrews and the choice of handle to suite your needs.
Da: Integrated Audio Front Face, With Double Thumb Screw, U-Pick Handle
An audio enhanced version of the standard front face with thumbscrews and the choice of handle to suite your needs.
![2: 3" Chrome Wire Pull 2: 3" Chrome Wire Pull](https://www.dithd.com/wp-content/uploads/2014/06/handle-2.png)
2: 3″ Chrome Wire Pull
2: 3" Chrome Wire Pull
Compact 3″ chrome plated pull mounted on face of your choice.
![3: 4" Chrome Wire Pull 3: 4" Chrome Wire Pull](https://www.dithd.com/wp-content/uploads/2014/06/handle-21.png)
3: 4″ Chrome Wire Pull
3: 4" Chrome Wire Pull
4″ chrome plated pull mounted on face of your choice.
4: 6" Chrome Wire Pull
Robust 6″ chrome plated wire pull mounted on face of your choice.
5: 4" Brushed Aluminum Pull
Smooth 4″ brushed aluminum pull mounted on face of your choice.
6: 7.5" Stainless Steel Pull
Solid 7.5″ stainless steel pull mounted on face of your choice.
8: 5" Collapsible Pull
Convenient and sturdy 5″ collapsible pull mounted on face of your choice in a black finish.
Dimensions: 19″ W x 1.75″ H x 20″ min D
Power Consumption: varies
Values are approximate and vary based on configuration
